This node works like the Wireframe node, but this node creates more complex tube geometry from curves, with smoother bends and intersections than Wireframe, especially for L-systems. (The Wireframe node creates transition surfaces where the original curve branches.)

The four numerical parameters support all the local variables of the Point operation, plus the LSYSTEM specific variables of $WIDTH, $SEGS, $DIV, $LAGE, $GEN, and $ARC.

Tip

You can disable end caps using a workaround. First, add an attribute wrangle between the input curve and the Polywire node with the following snippet:

// Create an attribute which is 1 if the point is interior and 0 // if it's at the end i@isinterior = neighbourcount(0, @ptnum) > 1;

Then, in the Polywire node, set **Smooth points** to `@isinterior`

.

## Parameters

Group

The group of polygons to convert to wires.

Wire Radius

This is the radius of the wire to sweep over the polygon.

Maximum Joint Scale

Prevent Joint Buckling scales up the intersection points so that they lie on the intersection of two tubes, rather than a width sized sphere. This can cause the points to be scaled past the first segment of the tube, however, causing buckling. This parameter allows you to change on a point level what the maximum scale applied to the points is.

Smooth Point

If the expression evaluates to a non-zero value for a point, the generated tube is smooth and connected through that point. If the expression is zero, the corresponding segment is disconnected. A value of zero will leave ends uncapped.

Divisions

This is the number of divisions in the circle which is to be swept over the polygon. It can vary on a point basis.

Segments

The number of segments to divide each edge of the polygon into. It can vary on a point basis.

Segment Scales

These are how far into the segment to make the first circle and how far towards the end to keep going. Both values are in the range 0-1, where 0 is the start and 1 the end. These are segment specific values. The local variable $NSEG is available here for the number of segments in the previous parameter.

Prevent Joint Buckling

This toggle when set will scale the intersection point of edges to avoid a collapse when sharp turns are made.

Do Vertex Textures

Toggles whether vertex textures are generated for the geometry. For best texturing of branch points, the points of the wire should be ordered so the "important" side has least point number. For example, in a Y branch, the bottom of the Y should have the smallest point numbers.

U Seam Offset

A per segment parameter which cycles how far around the tube the seam is placed. The seam is always snapped to the nearest polygon edge.

U Textures

Per segment values for the starting/ending values of the u texture.

V Textures

The same, but for v textures.

Joint Up Vector

If enabled, the up vector at each joint is set to the specified value. This will result in twisting of the branches.

## Locals

PTDIST

When resolving a segment, this is the distance between the end points of the segment.

NSEG

This is the number of segments which the segments parameter evaluated to for this segment.

## Examples

PolywireModel Example for PolyWire geometry node

This example demonstrates how the Polywire SOP builds polygonal geometry based on a polygonal frame, and how the parameters can be customized with local variables.
